Forklift Fuel Tanks - Nearly all fuel tanks are built; however various fuel tanks are made by trained craftspeople. Restored tanks or custom tanks could be found on automotive, tractors, motorcycles and aircraft.
There are a series of certain requirements to be followed when constructing fuel tanks. Commonly, the craftsman sets up a mockup in order to know the correct shape and size of the tank. This is usually performed from foam board. Then, design problems are dealt with, consisting of where the drain, outlet, seams, baffles and fluid level indicator would go. The craftsman needs to know the alloy, thickness and temper of the metallic sheet he would make use of to make the tank. Once the metal sheet is cut into the shapes needed, lots of pieces are bent to be able to make the basic shell and or the baffles and ends utilized for the fuel tank.
In aircraft and racecars, the baffles contain "lightening" holes, which are flanged holes which provide strength to the baffles, while likewise reducing the tank's weight. Openings are added toward the ends of construction for the fuel pickup, the filler neck, the fluid-level sending unit and the drain. Occasionally these holes are added once the fabrication method is done, other times they are made on the flat shell.
Then, the baffles and ends could be riveted into position. The rivet heads are often soldered or brazed in order to stop tank leaks. Ends could next be hemmed in and flanged and brazed, or soldered, or sealed with an epoxy type of sealant, or the ends can likewise be flanged and next welded. After the brazing, welding and soldering has been finished, the fuel tank is tested for leaks.
